The ICOM IC-F1100D/F2100D Series is a compact and durable range of professional digital two-way radios, designed for reliable performance in demanding environments. Featuring a rugged, waterproof, and dust-tight chassis, these radios deliver powerful 1500 mW audio output and outstanding voice clarity, thanks to Icom’s enhanced speaker design.
With intelligent emergency functions, a long-lasting battery, and versatile operational modes, the IC-F1100D/F2100D radios are ideal for both everyday business use and critical communication needs.
Choose from three versions depending on your operational needs:
IC-F1100D (VHF) / IC-F2100D (UHF): No display
IC-F1100DS (VHF) / IC-F2100DS (UHF): Display with 4-key keypad
IC-F1100DT (VHF) / IC-F2100DT (UHF): Full keypad with LCD display
Digital IDAS™ 6.25 kHz operation
128 channels / 8 zones (LCD models), 16 channels (non-display models)
1500 mW high-power speaker with enhanced acoustics
Compact and lightweight: 52.2 (W) x 111.8 (H) mm (2.1 × 4.4 in)
IP67 / IP55 / IP54 dustproof and waterproof ratings
MIL-STD-810G military standard tested (12 categories)
AquaQuake™ function for automatic speaker water drainage
Long-lasting battery: up to 18 hours with supplied BP-280 (based on 5:5:90 duty cycle with Power Save)
Programmable keys with “shift” functionality
8-character alphanumeric display (LCD versions)
Multi-color LED indicator
NXDN™ Conventional
NXDN™ Multi-Site Conventional over IP
NXDN™ Type-D Single-Site Trunking
Analogue FM Mode
Mixed Analogue/Digital Mode
AMBE+2™ Vocoder for enhanced voice quality
Over-the-Air Alias (OAA) – displays caller ID without manual programming (LCD versions)
Individual, Group, and All Call
Late Entry for Group Calls
Status and polling messages
Short data messaging (LCD versions)
Call alert and radio check (receive only)
GPS support (with optional HM-171GPW speaker mic)
CTCSS and DTCS tone signaling
2-Tone and 5-Tone selective calling
MDC PTT ID
BIIS PTT ID
Digital voice scrambler (low-level encryption)
Analogue voice scrambler (16-code inversion)
Emergency button with programmable response
Man Down, Lone Worker, and Motion/Stationary detection
Remote Monitor, Stun, Revive, and Kill (RX only)
Surveillance mode disables beeps and LEDs
Power-On password protection (LCD models only)
Priority Scan for one or two channels
Voting Scan for automatic repeater selection
Mode Dependent Scan
Power-On Scan
Talk Back Timer
Channel announcement
VOX (voice-activated transmission)
Siren alert for emergency signaling
Digital/Analogue Compatibility: IDAS™, NXDN™, analogue FM, mixed mode
Audio Output: 1500 mW
Battery Life: Up to 18 hours with BP-280
Protection Rating: IP67 / IP55 / IP54
Safety Features: Man Down, Lone Worker, Voice Scrambler
Chargers & Power:
BC-123S: Fast charger power supply
BC-157S: AC adapter for multi-chargers (BC-197, BC-121N, BC-214)
BC-213: Single fast charger (approx. 2.5 hrs)
BC-214: 6-way charger (charges up to six BP-279s)
Battery Packs:
BP-278: 7.2V / 1130 mAh Li-Ion (approx. 10 hrs)
BP-279: 7.2V / 1485 mAh Li-Ion
BP-280: 7.2V / 2280 mAh Li-Ion (up to 18 hrs)
Antennas:
FA-SC25U / FA-SC57U / FA-SC72U: UHF antennas (various frequency ranges)
FA-SC55V / FA-SC56VS / FA-SC57VS: VHF and stubby antennas
Audio Accessories:
HM-153LA / HM-158LA / HM-159LA: Earphone and speaker microphones
HM-166LA / HM-168LWP / HM-171GPW: Lightweight, waterproof, GPS-ready microphones
HS-94 / HS-94LWP / HS-95 / HS-95LWP / HS-97: Headsets with earpiece, boom, or throat mics
HM-2PL-OW / PRO-P180LA: Covert earpiece and mic solutions
VS-4LA: External PTT switch for headset use
Mounts & Clips:
MB-1000: Vehicle mounting bracket
MB-130: Vehicle charger bracket (for use with BC-213 or BC-160)
MB-133: Alligator belt clip
Cables:
OPC-2004LA: Headset adapter cable
OPC-478UC: USB cloning cable
OPC-656: DC power cable
Multi-Charging:
UK6WAY: Icom UK-sourced 6-way charger compatible with IC-F1100D/F2100D and other models
Direct Mode (Peer-to-Peer): Ideal for standard PMR use
Repeater-Linked Systems: Supports base station, repeater, and gateway integration (telephone, IP, etc.)
